Details of Electric Forklift

Model		FU05	FU10	FU15	FU18	FU20	FU25	FU30	FU35
Loading capacity	KG	500	1000	1500	1800	2000	2500	3000	3500
Load center distance	mm	300	500	500	500	500	500	500	500
Overall length	Fork/mm	2520	3170	3170	3200	3380	3380	3630	3630
Overall length	No fork/mm	1450	2100	2100	2130	2310	2310	2560	2560
Overall width	mm	742	900	900	1050	1050	1050	1220	1220
Wheelbase	mm	885	1180	1180	1335	1515	1515	1680	1680
Front suspension distance	mm	280	340	340	483	483	483	425	425
Rear distance	mm	300	490	490	400	400	400	425	425
Front wheel tread	mm	742	955	955	900	970	970	1000	1000
Rear wheel tread	mm	670	890	890	920	950	950	980	980
Min.height off the ground	mm	90	90	90	110	135	135	145	145
Max.lifting height	mm	2000	3000	3000	3000	3000	3000	3000	3000
Free lifting height	mm	80	80	80	80	170	170	160	160
Min.outside truning radius	mm	1200	1500	1500	1950	2050	2050	2200	2200
Min.right channel width	mm	1600	2000	2000	3400	3760	3760	4100	4100
Max.lifting speed with empty load	mm/s	300	300	300	350	400	380	450	425
Max.lifting speed with full load	mm/s	260	260	260	300	300	280	280	260
Net weight	kg	820	1850	2000	3500	4050	4200	4950	5600
Tyre type(front/rear)		solid tyre	solid tyre	solid tyre	solid tyre	solid tyre	solid tyre	solid tyre	solid tyre

Maintenance Free of Electric Forklift

Handicap Scissor Lift

Handicap Wheel Chair Lift

Over 75% capacity reserved after 4000 shifts operation.
Longer service life than lead-acid battery in equal working condition.
5 years or ten thousand hours quality guarantee for high performance lithium battery assembly.
